RDG100 header image

RDG100

Generator

RDG100 product image
High end 3-phase Generators. With the higher range generators you can run a factory.
  • Auto start: detects when the electricity from municipal power gets cut off and automatically starts (With a delay of your choice, as low as 1 second)
  • High 3-phase 380+ volt output
  • Automatic throttle for load handling.?
  • Quiet running in sound proof casing
  • Electronic regulating and key / push button start
  • High product quality, made from the top quality materials
  • Well ventilated?
  • Permanent fixture installation?

Featured Specs

Machine Specs

Prime Power:
100kVA

Output:
400V

Specifications

Machine Specs
+
SpecValue
100 kVA
110 kVA
Weifang
1,400 kg
400 V
Dimensions
+
SpecValue
2900 x 1000 x 1700 mm
Engine
+
SpecValue
Diesel
R6105ZD
6
105 mm
125 mm
1,500 rpm
6.49 L
Turbocharged
Electric Starting
Mechanical Governor
Closed Water Cooling
218 g/kw.h
80 kW
Alternator
+
SpecValue
WP274C
100% Pure Copper
144 A
50 Hz
1,500 rpm
400 V
0.8 LAG
3P4W
AVR
H
